GAI L Rechte opschroefkoppeling Whitworth binnendraad

string(138) "https://www.hydynamic.nl/wp-content/uploads/product_pdfs/snijringkoppelingen-rvs/gai-l-rechte-opschroefkoppeling-whitworth-binnendraad.pdf"
string(162) "/home/hydynamic/domains/hydynamic.nl/public_html/wp-content/uploads/product_pdfs/snijringkoppelingen-rvs/gai-l-rechte-opschroefkoppeling-whitworth-binnendraad.pdf"

Variations:

Partnr Draad d2 Druk (bar) I (mm) I1 ca_ (mm) I2 Description Pijpopname d1 (mm) SW1 SW3
0431-0123-0602 G1/8 315 12 34 19 GAI6LR 1/8 L6 14 14 Do a quotationarray(10) { ["pa_bestelnummer"]=> string(14) "0431-0123-0602" ["pa_draad-d2"]=> string(4) "g1-8" ["pa_druk-bar"]=> string(3) "315" ["pa_i-mm"]=> string(2) "12" ["pa_i1-ca_-mm"]=> string(2) "34" ["pa_i2"]=> string(2) "19" ["pa_omschrijving"]=> string(10) "gai6lr-1-8" ["pa_pijpopname-d1-mm"]=> string(2) "l6" ["pa_sw1"]=> string(5) "14-en" ["pa_sw3"]=> string(5) "14-en" }
0431-0123-1006 G3/8 315 17 41 26 GAI10LR 3/8 L10 24 19 Do a quotationarray(10) { ["pa_bestelnummer"]=> string(14) "0431-0123-1006" ["pa_draad-d2"]=> string(4) "g3-8" ["pa_druk-bar"]=> string(3) "315" ["pa_i-mm"]=> string(2) "17" ["pa_i1-ca_-mm"]=> string(2) "41" ["pa_i2"]=> string(2) "26" ["pa_omschrijving"]=> string(11) "gai10lr-3-8" ["pa_pijpopname-d1-mm"]=> string(3) "l10" ["pa_sw1"]=> string(5) "24-en" ["pa_sw3"]=> string(5) "19-en" }
0431-0123-1008 G1/2 315 20 45 30 GAI10LR 1/2 L10 27 19 Do a quotationarray(10) { ["pa_bestelnummer"]=> string(14) "0431-0123-1008" ["pa_draad-d2"]=> string(4) "g1-2" ["pa_druk-bar"]=> string(3) "315" ["pa_i-mm"]=> string(2) "20" ["pa_i1-ca_-mm"]=> string(2) "45" ["pa_i2"]=> string(2) "30" ["pa_omschrijving"]=> string(11) "gai10lr-1-2" ["pa_pijpopname-d1-mm"]=> string(3) "l10" ["pa_sw1"]=> string(2) "27" ["pa_sw3"]=> string(5) "19-en" }
0431-0123-1204 G1/4 315 17 40 25 GAI12LR 1/4 L12 19 22 Do a quotationarray(10) { ["pa_bestelnummer"]=> string(14) "0431-0123-1204" ["pa_draad-d2"]=> string(4) "g1-4" ["pa_druk-bar"]=> string(3) "315" ["pa_i-mm"]=> string(2) "17" ["pa_i1-ca_-mm"]=> string(2) "40" ["pa_i2"]=> string(2) "25" ["pa_omschrijving"]=> string(11) "gai12lr-1-4" ["pa_pijpopname-d1-mm"]=> string(3) "l12" ["pa_sw1"]=> string(5) "19-en" ["pa_sw3"]=> string(5) "22-en" }
0431-0123-1206 G3/8 315 17 41 26 GAI12LR 3/8 L12 24 22 Do a quotationarray(10) { ["pa_bestelnummer"]=> string(14) "0431-0123-1206" ["pa_draad-d2"]=> string(4) "g3-8" ["pa_druk-bar"]=> string(3) "315" ["pa_i-mm"]=> string(2) "17" ["pa_i1-ca_-mm"]=> string(2) "41" ["pa_i2"]=> string(2) "26" ["pa_omschrijving"]=> string(11) "gai12lr-3-8" ["pa_pijpopname-d1-mm"]=> string(3) "l12" ["pa_sw1"]=> string(5) "24-en" ["pa_sw3"]=> string(5) "22-en" }
0431-0123-1208 G1/2 315 20 45,5 31 GAI12LR 1/2 L12 27 22 Do a quotationarray(10) { ["pa_bestelnummer"]=> string(14) "0431-0123-1208" ["pa_draad-d2"]=> string(4) "g1-2" ["pa_druk-bar"]=> string(3) "315" ["pa_i-mm"]=> string(2) "20" ["pa_i1-ca_-mm"]=> string(3) "455" ["pa_i2"]=> string(2) "31" ["pa_omschrijving"]=> string(11) "gai12lr-1-2" ["pa_pijpopname-d1-mm"]=> string(3) "l12" ["pa_sw1"]=> string(2) "27" ["pa_sw3"]=> string(5) "22-en" }
0431-0123-1508 G1/2 315 20 46 31 GAI15LR 1/2 L15 27 27 Do a quotationarray(10) { ["pa_bestelnummer"]=> string(14) "0431-0123-1508" ["pa_draad-d2"]=> string(4) "g1-2" ["pa_druk-bar"]=> string(3) "315" ["pa_i-mm"]=> string(2) "20" ["pa_i1-ca_-mm"]=> string(2) "46" ["pa_i2"]=> string(2) "31" ["pa_omschrijving"]=> string(11) "gai15lr-1-2" ["pa_pijpopname-d1-mm"]=> string(3) "l15" ["pa_sw1"]=> string(2) "27" ["pa_sw3"]=> string(2) "27" }
0431-0123-1808 G1/5 315 20 47 30,5 GAI18LR 1/2 L18 27 32 Do a quotationarray(10) { ["pa_bestelnummer"]=> string(14) "0431-0123-1808" ["pa_draad-d2"]=> string(4) "g1-5" ["pa_druk-bar"]=> string(3) "315" ["pa_i-mm"]=> string(2) "20" ["pa_i1-ca_-mm"]=> string(2) "47" ["pa_i2"]=> string(3) "305" ["pa_omschrijving"]=> string(11) "gai18lr-1-2" ["pa_pijpopname-d1-mm"]=> string(3) "l18" ["pa_sw1"]=> string(2) "27" ["pa_sw3"]=> string(2) "32" }
0431-0123-2212 G3/4 160 22 52 35,5 GAI22LR 3/4 L22 36 36 Do a quotationarray(10) { ["pa_bestelnummer"]=> string(14) "0431-0123-2212" ["pa_draad-d2"]=> string(4) "g3-4" ["pa_druk-bar"]=> string(3) "160" ["pa_i-mm"]=> string(2) "22" ["pa_i1-ca_-mm"]=> string(2) "52" ["pa_i2"]=> string(3) "355" ["pa_omschrijving"]=> string(11) "gai22lr-3-4" ["pa_pijpopname-d1-mm"]=> string(3) "l22" ["pa_sw1"]=> string(2) "36" ["pa_sw3"]=> string(2) "36" }
0431-0123-2816 G1 160 24,5 54,5 38 GAI28LR 1 L28 41 41 Do a quotationarray(10) { ["pa_bestelnummer"]=> string(14) "0431-0123-2816" ["pa_draad-d2"]=> string(2) "g1" ["pa_druk-bar"]=> string(3) "160" ["pa_i-mm"]=> string(3) "245" ["pa_i1-ca_-mm"]=> string(3) "545" ["pa_i2"]=> string(2) "38" ["pa_omschrijving"]=> string(9) "gai28lr-1" ["pa_pijpopname-d1-mm"]=> string(3) "l28" ["pa_sw1"]=> string(2) "41" ["pa_sw3"]=> string(2) "41" }
0431-0123-3520 G1 1/4 160 26,5 62,5 41 GAI35LR 1 1/4 L35 55 50 Do a quotationarray(10) { ["pa_bestelnummer"]=> string(14) "0431-0123-3520" ["pa_draad-d2"]=> string(6) "g1-1-4" ["pa_druk-bar"]=> string(3) "160" ["pa_i-mm"]=> string(3) "265" ["pa_i1-ca_-mm"]=> string(3) "625" ["pa_i2"]=> string(2) "41" ["pa_omschrijving"]=> string(13) "gai35lr-1-1-4" ["pa_pijpopname-d1-mm"]=> string(3) "l35" ["pa_sw1"]=> string(2) "55" ["pa_sw3"]=> string(2) "50" }
0431-0123-4224 G1 1/2 160 28,5 65,5 42,5 GAI42LR 1 1/2 L42 60 60 Do a quotationarray(10) { ["pa_bestelnummer"]=> string(14) "0431-0123-4224" ["pa_draad-d2"]=> string(6) "g1-1-2" ["pa_druk-bar"]=> string(3) "160" ["pa_i-mm"]=> string(3) "285" ["pa_i1-ca_-mm"]=> string(3) "655" ["pa_i2"]=> string(3) "425" ["pa_omschrijving"]=> string(13) "gai42lr-1-1-2" ["pa_pijpopname-d1-mm"]=> string(3) "l42" ["pa_sw1"]=> string(2) "60" ["pa_sw3"]=> string(2) "60" }
